Porcelain 1130W/32 Pin-Type Insulators – 11kV Overhead Power Lines
The Porcelain 1130W/32 Pin-Type Insulators are robust and dependable solution for insulation and conductor support in 11kV overhead transmission and distribution lines.
Manufactured by Bonle (Fujian) Insulator Co., Ltd. and designed by WU REN GUO, this insulator ensures seamless integration into power networks across New Zealand and other markets that require high mechanical strength and reliable electrical performance.
The 1130W/32 Pin-Type Insulators feature a specialized unglazed (No Glazed) and semi-conductive porcelain finish, providing excellent pollution performance and long-term durability in outdoor environments.
With its rugged construction, this insulator offers exceptional mechanical strength (11kN cantilever) and a high creepage distance (250mm) for reliable operation under harsh conditions.
Porcelain 1130W/32 Pin-Type Insulators – Model Designation Breakdown
The designation 1130W/32 Pin-Type Insulators is a specific manufacturer product code. The breakdown below reflects its primary application and design features:
| Code | Meaning |
| 1130 | Model series / 11kV class insulator |
| W | Withstand / Weather-resistant profile |
| 32 | Specific design variant / dimension code |
1130W/32 Pin-Type Insulators Porcelain – Technical Specifications
| Parameter | Value |
| Model | 1130W/32 |
| Standard | AS/NZS compliant (Design reference) |
| Typical Application Voltage | 11 kV |
| Height (H) | 155 mm |
| Diameter (D) | 129 mm |
| Nominal Minimum Creepage Distance | 250 mm |
| Protected Creepage Distance | 125 mm |
| Flashover Distance | 150 mm |
| Lightning Impulse Withstand Voltage | 99 kV |
| Power Frequency Withstand Voltage (Dry) | 65 kV |
| Power Frequency Withstand Voltage (Wet – Vertical) | 35 kV |
| Power Frequency Withstand Voltage (Wet – Horizontal) | 40 kV |
| Power Frequency Flashover Voltage (Dry) | 70 kV |
| Power Frequency Flashover Voltage (Wet – Vertical) | 45 kV |
| Power Frequency Flashover Voltage (Wet – Horizontal) | 50 kV |
| Power Frequency Withstand Puncture Voltage | 160 kV |
| Minimum Bending Failing Load | 11 kN |
| Surface Finish | Unglazed (No Glazed) / Semi-conductive |
| Manufacturer | BONLE (MINQING) LOW VOLTAGE ELECTRIC CO.,LTD. |
| Designer | WU REN GUO |
1130W/32 Pin-Type Insulators Porcelain – Key Features
Superior Electrical Performance – The 1130W/32 insulator delivers reliable electrical performance for 11kV systems, with a nominal minimum creepage distance of 250 mm that effectively increases leakage distance and reduces the risk of pollution flashover.
Testing and verification follow AS/NZS 2947.1 – Test methods for insulator units, guaranteeing safe operation of 11kV lines even under rain, fog, and contaminated conditions.
High Mechanical Strength – With a minimum bending failing load of 11 kN, the insulator reliably withstands conductor tension, wind loads, and ice accretion, ensuring long-term stability in overhead line installations. For installation best practices, refer to our Insulator installation guide for 11kV overhead lines.
Semi-Conductive & Unglazed Design – The drawing specifies a “semi-conductive” and “No Glazed” surface. This specialized finish is designed to optimize pollution performance and reduce radio interference in heavily contaminated environments.
Research on semi-conducting glaze insulator performance demonstrates that semi-conductive glazed insulators exhibit higher flashover voltages under contaminated and wet conditions compared with conventional porcelain insulators.
Simple Structure, Easy Installation – The pin-type insulator features a one-piece porcelain body designed for convenient mounting on standard pins. The conductor is secured in the side groove or on the neck of the insulator using standard binding methods.
Reliable Design – Engineered for long-term reliable operation with minimal maintenance requirements – regular visual inspections and cleaning are typically sufficient to ensure continued performance.
1130W/32 Pin-Type Insulators Porcelain – Application Scenarios
The 1130W/32 high-voltage pin-type insulator is ideal for:
- Insulation and conductor support in 11kV overhead distribution and transmission lines
- Outdoor installations with exposure to all atmospheric factors
- AC overhead power lines with frequencies not exceeding 100 Hz
- Power distribution networks in normal environmental conditions
- Installation on wooden, reinforced concrete, and metal poles
- Medium voltage distribution networks in New Zealand and other AS/NZS-standard markets
- Mounting options – can be used vertically or horizontally
For projects involving different voltage classes or mechanical load requirements, explore our related product ranges such as 11kV strain insulators for overhead lines, 22kV pin type insulators for high voltage, and Porcelain shackle insulators – 650V & 3300V.
1130W/32 Pin-Type Insulators Porcelain – Standards Compliance
| Standard | Description |
| AS 4899-2007 | Pin insulators — Porcelain and glass for overhead power lines — Voltages greater than 1000 V a.c. |
| AS/NZS 2947.1 | Test methods — Insulator units |
| AS 1824.1 | Insulation co-ordination — Definitions, principles and rules |
| AS 4436 | Guide for the selection of insulators in respect of polluted conditions |
| AS 1154.1 | Insulator and conductor fittings for overhead power lines – Performance, material, general requirements and dimensions |
For a comprehensive overview of how these standards apply to your specific project, visit our AS/NZS standards compliance overview.
1130W/32 Pin-Type Insulators Porcelain – Recommended Pin Type
The 1130W/32 Pin-Type Insulators is designed to be used with standard 11kV pin assemblies. For specific pin specifications, please refer to the manufacturer’s installation guidelines or the relevant AS/NZS standard.
| Parameter | Value |
| Pin Type Reference | Standard 11kV Pin (Refer to manufacturer) |
| Cantilever Minimum Failing Load | 11 kN |
| Head Pattern | Type 1 / Standard |
Why Choose 1130W/32 Pin-Type Insulators Porcelain for Your Power Grid?
- Full compliance – designed to meet relevant AS/NZS standards, ensuring smooth acceptance by grid operators and regulatory bodies in New Zealand.
- Proven reliability – engineered with high mechanical strength (11 kN bending failing load) and robust electrical performance (160 kV puncture).
- Pollution-resistant design – 250 mm creepage distance and semi-conductive unglazed surface ensure reliable operation in normal to polluted environments. See our Pollution level selection guide for insulators for more details.
- Weather-resistant – durable porcelain body provides excellent weather resistance and UV protection.
- Cost-effective – high performance at competitive pricing, reducing total project costs.
- Versatile – suitable for 11kV applications and available with custom surface finishes.
About the 1130W/32 Pin-Type Insulators Porcelain Manufacturer
The 1130W/32 Pin-Type Insulators Porcelain is manufactured by BONLE (MINQING) LOW VOLTAGE ELECTRIC CO.,LTD., a leading Chinese insulator manufacturer with decades of experience in power line products. This manufacturer holds ISO 9001 certification and produces insulators in accordance with IEC, ANSI, ASTM, AS, BS, DIN, and ISO standards. All products undergo rigorous electrical and mechanical testing before shipment, ensuring the highest quality standards. View the full BONLE official pin insulator product range for related product specifications and technical documentation.
Designer: WU REN GUO
Model: 1130W/32 | Standard: AS/NZS Compliant | Rated Voltage: 11 kV | Creepage Distance: 250 mm | Cantilever Strength: 11 kN
